目的
演示利用kubernem安装k8s来使用pod安全策略。
Pod安全策略是一种机制，用于限制容器在k8s上运行时可执行的操作，例如防止其作为特权容器的运行，和主机网络运行等。
阅读文档，了解如何使用它来提高安全性
我尽可能的寻找有关引导kubeadm集群的所有信息，内容如下：
TLDR
这个帖子很长，所以我做了一个完整的说明，也就是说你需要：
在master节点运行kubeadm init并启用PodSecurityPolicy admission controller
使用RBAC配置添加一些pod安全策略 - 足够启动CNI和DNS等
没有它，CNI daemonsets将无法启动
应用您的CNI插件，该插件可以使用以前创建的一个pod安全策略
通过kubeadm join完成向集群添加节点的配置
在向集群添加更多工作负载时，请检查是否需要额外的pod安全策略和RBAC配置
我们将要做什么
这是我在kubeadm上安装运行pod安全策略所采取的步骤
为master节点的初始化配置pod安全策略 admission controller
为网络层组件配置一些pod安全策略
配置CNI插件 - 这里将使用flannel
然后将使用下面的代码演示一些其他的pod安全策略方案
安装一个具有一些特定要求的nginx-ingress controller - 这只是为了说明添加额外的策略
安装没有特定pod安全策略要求的常规服务 - 基于httpbin.org
环境
将只在单个节点说明，而不是具有高可用集群的多节点集群
Ubuntu
根据kubeadm的要求切换
为UTC配置时区
Docker
假设当前用户在docker组中
kubernetes 1.11.3 - 使用RBAC
master节点配置
按照说明安装kubeadm（链接如下）
https://kubernetes.io/docs/setup/production-environment/tools/kubeadm/install-kubeadm/
让我们安装jq，我们将用它来进行一些json输出处理
sudo apt-get update
sudo apt-get install -y jq验证kubeadm的版本
sudo kubeadm version接着我们将为下面创建的内容创建一个目录，在以下所有说明中我们假设您在此目录中
mkdir ~/psp-inv
cd ~/psp-inv
kubeadm配置文件
将创建这个文件，并将其用于master上的kubeadm init
使用此内容创建一个kubeadm-config.yaml文件 - 请注意我们必须为flannel指定pod子网为10.244.0.0/16
请注意，此文件对于此演示是最小的，如果您使用更高版本的kubeadm，则可能需要更改apiVersion
apiVersion: kubeadm.k8s.io/v1alpha2
kind: MasterConfiguration
apiServerExtraArgs:
enable-admission-plugins: PodSecurityPolicy
controllerManagerExtraArgs:
address: 0.0.0.0
kubernetesVersion: v1.11.3
networking:
podSubnet: 10.244.0.0/16
schedulerExtraArgs:
address: 0.0.0.0
Master init
sudo kubeadm init --config kubeadm-config.yaml根据上面命令输出的说明获取您自己的kubeconfig文件副本
如果要将工作节点添加到集群，请注意加入以下信息
让我们检查master节点的状态
kubectl get nodes
NAME STATUS ROLES AGE VERSION
pmcgrath-k8s-master NotReady master 1m v1.11.3这样说明节点还没有准备好，因为它正在等待CNI
让我们检查一下pods
kubectl get pods --all-namespaces
No resources found.所以，如果我们没有启用pod security policy admission control，通常看不到任何正在运行的pod
让我们检查 docker
docker container ls --format '{{ .Names }}'
k8s_kube-scheduler_kube-scheduler-pmcgrath-k8s-master_kube-system_a00c35e56ebd0bdfcd77d53674a5d2a1_0
k8s_kube-controller-manager_kube-controller-manager-pmcgrath-k8s-master_kube-system_fd832ada507cef85e01885d1e1980c37_0
k8s_etcd_etcd-pmcgrath-k8s-master_kube-system_16a8af6b4a79e9b0f81092f85eab37cf_0
k8s_kube-apiserver_kube-apiserver-pmcgrath-k8s-master_kube-system_db201a8ecaf8e99623b425502a6ba627_0
k8s_POD_kube-controller-manager-pmcgrath-k8s-master_kube-system_fd832ada507cef85e01885d1e1980c37_0
k8s_POD_kube-scheduler-pmcgrath-k8s-master_kube-system_a00c35e56ebd0bdfcd77d53674a5d2a1_0
k8s_POD_kube-apiserver-pmcgrath-k8s-master_kube-system_db201a8ecaf8e99623b425502a6ba627_0
k8s_POD_etcd-pmcgrath-k8s-master_kube-system_16a8af6b4a79e9b0f81092f85eab37cf_0所有容器都在运行，但这不是通过kubectl获取的信息
让我们检查事件
kubectl get events --namespace kube-system会看到类似这样的错误：pods “kube-proxy-“ is forbidden: no providers available to validate pod request
配置pod安全策略
我已经配置了
任何工作负载都可以使用默认的pod安全策略，它没有什么特权，但应该适用于大多数工作负载
将创建一个RBAC ClusterRole
将为所有经过身份验证的用户创建RBAC ClusterRoleBinding
我授予kube-system命名空间中的节点和所有服务帐户访问权限的特权pod安全策略
考虑这个权限应该被限制在这个命名空间内
应该只在此命名空间中运行k8s组件
将创建一个RBAC ClusterRole
将在kube-system命名空间中创建RBAC RoleBinding
使用此内容创建default-psp-with-rbac.yaml文件
apiVersion: policy/v1beta1
kind: PodSecurityPolicy
metadata:
annotations:
apparmor.security.beta.kubernetes.io/allowedProfileNames: 'runtime/default'
apparmor.security.beta.kubernetes.io/defaultProfileName: 'runtime/default'
seccomp.security.alpha.kubernetes.io/allowedProfileNames: 'docker/default'
seccomp.security.alpha.kubernetes.io/defaultProfileName: 'docker/default'
name: default
spec: allowedCapabilities: [] # default set of capabilities are implicitly allowed
allowPrivilegeEscalation: false
fsGroup:
rule: 'MustRunAs'
ranges:
# Forbid adding the root group.
- min: 1
max: 65535
hostIPC: false
hostNetwork: false
hostPID: false
privileged: false
readOnlyRootFilesystem: false
runAsUser:
rule: 'MustRunAsNonRoot'
seLinux:
rule: 'RunAsNonRoot'
supplementalGroups:
rule: 'RunAsNonRoot'
ranges:
# Forbid adding the root group.
- min: 1
max: 65535
volumes:
- 'configMap'
- 'downwardAPI'
- 'emptyDir'
- 'persistentVolumeClaim'
- 'projected'
- 'secret'
hostNetwork: false
runAsUser:
rule: 'RunAsAny'
seLinux:
rule: 'RunAsAny'
supplementalGroups:
rule: 'RunAsAny'
fsGroup:
rule: 'RunAsAny'
---
# Cluster role which grants access to the default pod security policy
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
name: default-psp
rules:
- apiGroups:
- policy
resourceNames:
- default
resources:
- podsecuritypolicies
verbs:
- use
---
# Cluster role binding for default pod security policy granting all authenticated users access
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
name: default-psp
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: default-psp
subjects:
- apiGroup: rbac.authorization.k8s.io
kind: Group
name: system:authenticated使用此内容创建privileged-psp-with-rbac.yaml文件
# Should grant access to very few pods, i.e. kube-system system pods and possibly CNI pods
apiVersion: policy/v1beta1
kind: PodSecurityPolicy
metadata:
annotations:
# See https://kubernetes.io/docs/concepts/policy/pod-security-policy/#seccomp
seccomp.security.alpha.kubernetes.io/allowedProfileNames: '*'
name: privileged
spec:
allowedCapabilities:
- '*'
allowPrivilegeEscalation: true
fsGroup:
rule: 'RunAsAny'
hostIPC: true
hostNetwork: true
hostPID: true
hostPorts:
- min: 0
max: 65535
privileged: true
readOnlyRootFilesystem: false
runAsUser:
rule: 'RunAsAny'
seLinux:
rule: 'RunAsAny'
supplementalGroups:
rule: 'RunAsAny'
volumes:
- '*'
---
# Cluster role which grants access to the privileged pod security policy
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
name: privileged-psp
rules:
- apiGroups:
- policy
resourceNames:
- privileged
resources:
- podsecuritypolicies
verbs:
- use
---
# Role binding for kube-system - allow nodes and kube-system service accounts - should take care of CNI i.e. flannel running in the kube-system namespace
# Assumes access to the kube-system is restricted
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: kube-system-psp
namespace: kube-system
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: privileged-psp
subjects:
# For the kubeadm kube-system nodes
- apiGroup: rbac.authorization.k8s.io
kind: Group
name: system:nodes
# For all service accounts in the kube-system namespace
- apiGroup: rbac.authorization.k8s.io
kind: Group
name: system:serviceaccounts:kube-system
使用RBAC配置应用上述pod安全策略
kubectl apply -f default-psp-with-rbac.yaml
kubectl apply -f privileged-psp-with-rbac.yaml
校验
一段时间后，网络层pods将处于运行状态，coredns pods将挂起-等待CNI
kubectl get pods --all-namespaces --output wide --watch在配置CNI之前,网络层pods将再次启动失败，因为节点仍未准备就绪
安装flannel
看到这里（链接如下）
https://github.com/coreos/flannel
只有现在存在有特权 pod安全策略才能完成此操作，并且kube-system 中的flannel服务帐户将能够使用
如果使用不同的CNI插件，则应使用其安装说明，可能需要修改用于kubeadm init的kubeadm-config.yaml文件中的podSubnet
kubectl apply -f https://raw.githubusercontent.com/coreos/flannel/master/Documentation/kube-flannel.yml
再次校验
kubectl get pods --all-namespaces --output wide --watch所有pods最终将进入运行状态，包括coredns pod(s)
kubectl get nodes节点现已准备就绪
允许master上的工作负载
如果你想启动工作节点，你可以正常使用kubeadm join命令，利用kubeadm init输出，在这里跳过。
这些工作节点上没有特别需要加入集群pod安全策略
允许master节点上的工作负载，因为我们只是尝试在单个节点集群上进行验证
kubectl taint nodes --all node-role.kubernetes.io/master-
nginx ingress
将使用此处（链接如下）的清单
https://raw.githubusercontent.com/kubernetes/ingress-nginx/master/deploy/mandatory.yaml
这将创建一个新的命名空间和单个实例ingress controller，足以说明额外的pod安全策略
命名空间
由于命名空间尚不存在，因此我们可以创建，以便我们可以引用服务帐户
kubectl create namespace ingress-nginx
让我们创建一个pod安全策略
此pod安全策略基于deployment清单
使用此内容创建文件nginx-ingress-psp-with-rbac.yaml
apiVersion: policy/v1beta1
kind: PodSecurityPolicy
metadata:
annotations:
# Assumes apparmor available
apparmor.security.beta.kubernetes.io/allowedProfileNames: 'runtime/default'
apparmor.security.beta.kubernetes.io/defaultProfileName: 'runtime/default'
seccomp.security.alpha.kubernetes.io/allowedProfileNames: 'docker/default'
seccomp.security.alpha.kubernetes.io/defaultProfileName: 'docker/default'
name: ingress-nginx
spec:
# See nginx-ingress-controller deployment at https://github.com/kubernetes/ingress-nginx/blob/master/deploy/mandatory.yaml
# See also https://github.com/kubernetes-incubator/kubespray/blob/master/roles/kubernetes-apps/ingress_controller/ingress_nginx/templates/psp-ingress-nginx.yml.j2
allowedCapabilities:
- NET_BIND_SERVICE
allowPrivilegeEscalation: true
fsGroup:
rule: 'MustRunAs'
ranges:
- min: 1
max: 65535
hostIPC: false
hostNetwork: false
hostPID: false
hostPorts:
- min: 80
max: 65535
privileged: false
readOnlyRootFilesystem: false
runAsUser:
rule: 'MustRunAsNonRoot'
ranges:
- min: 33
max: 65535
seLinux:
rule: 'RunAsAny'
supplementalGroups:
rule: 'MustRunAs'
ranges:
# Forbid adding the root group.
- min: 1
max: 65535
volumes:
- 'configMap'
- 'downwardAPI'
- 'emptyDir'
- 'projected'
- 'secret'
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
name: ingress-nginx-psp
namespace: ingress-nginx
rules:
- apiGroups:
- policy
resourceNames:
- ingress-nginx
resources:
- podsecuritypolicies
verbs:
- use
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: ingress-nginx-psp
namespace: ingress-nginx
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: Role
name: ingress-nginx-psp
subjects:
# Lets cover default and nginx-ingress-serviceaccount service accounts
# Could have altered default-http-backend deployment to use the same service acccount to avoid granting the default service account access
- kind: ServiceAccount
name: default
- kind: ServiceAccount
name: nginx-ingress-serviceaccount让我们先创建
kubectl apply -f nginx-ingress-psp-with-rbac.yaml
创建nginx-ingress工作负载
将删除controller-publish-service arg，因为我们在这里不需要
curl -s https://raw.githubusercontent.com/kubernetes/ingress-nginx/master/deploy/mandatory.yaml | sed '/--publish-service/d' | kubectl apply -f -检查pods
kubectl get pods --namespace ingress-nginx --watch现在可以看到pod安全策略附加了注释
kubectl get pods --namespace ingress-nginx --selector app.kubernetes.io/name=ingress-nginx -o json | jq -r '.items[0].metadata.annotations."kubernetes.io/psp"'
Httpbin.org工作负载
让我们部署一个工作负载，其中默认的pod安全策略就足够了
使用此内容创建一个httpbin.yaml文件
apiVersion: apps/v1
kind: Deployment
metadata:
labels:
app.kubernetes.io/name: httpbin
name: httpbin
spec:
replicas: 1
selector:
matchLabels:
app.kubernetes.io/name: httpbin
template:
metadata:
labels:
app.kubernetes.io/name: httpbin
spec:
containers:
- args: ["-b", "0.0.0.0:8080", "httpbin:app"]
command: ["gunicorn"]
image: docker.io/kennethreitz/httpbin:latest
imagePullPolicy: Always
name: httpbin
ports:
- containerPort: 8080
name: http
restartPolicy: Always
---
apiVersion: extensions/v1beta1
kind: Ingress
metadata:
annotations:
kubernetes.io/ingress.class: "nginx"
labels:
app.kubernetes.io/name: httpbin
name: httpbin
spec:
rules:
- host: my.httpbin.com
http:
paths:
- path:
backend:
serviceName: httpbin
servicePort: 8080
---
apiVersion: v1
kind: Service
metadata:
labels:
app.kubernetes.io/name: httpbin
name: httpbin
spec:
ports:
- name: http
port: 8080
selector:
app.kubernetes.io/name: httpbin创建命名空间并在工作负载里运行
kubectl create namespace demo
kubectl apply --namespace demo -f httpbin.yaml让我们检查pod是否存在以及是否使用了默认策略
kubectl get pods --namespace demo
kubectl get pods --namespace demo --selector app.kubernetes.io/name=httpbin -o json | jq -r '.items[0].metadata.annotations."kubernetes.io/psp"'
测试工作负载
将通过调用 ingress controller pod实例， - 我没有这个演示的ingress服务
# Get nginx ingress controller pod IP
nginx_ip=$(kubectl get pods --namespace ingress-nginx --selector app.kubernetes.io/name=ingress-nginx --output json | jq -r .items[0].status.podIP)
# Test ingress and out httpbin workload
curl -H 'Host: my.httpbin.com' http://$nginx_ip/get
重置
如果像我一样经常弄乱它，你可以重置并重启
# Note: Will loose PKI also which is fine here as kubeadm master init will re-create
sudo kubeadm reset
# Should flush iptable rules after a kubeadm reset, see https://blog.heptio.com/properly-resetting-your-kubeadm-bootstrapped-cluster-nodes-heptioprotip-473bd0b824aa
sudo iptables -F && sudo iptables -t nat -F && sudo iptables -t mangle -F && sudo iptables -X
链接
文档
https://kubernetes.io/docs/concepts/policy/pod-security-policy
Github发表评论
https://github.com/kubernetes/kubernetes/issues/62566#issuecomment-381360838
安全建议
https://github.com/freach/kubernetes-security-best-practice/tree/master/PSP
GCE政策
https://github.com/kubernetes/kubernetes/tree/master/cluster/gce/addons/podsecuritypolicies
往期推荐
在K8s上使用具有Vault的Spring Boot
如何使用Message Queues, Spring Boot和Kubernetes规模化微服务（上篇）
如何使用Message Queues, Spring Boot和Kubernetes规模化微服务（下篇）
应用程序安全性和准确性不能被移交给Istio或任何服务网格
Windows Server 2019上的Docker 入门

点击阅读原文查看英文原文~
